Yingfeng Machinery - 1400 Degree Industrial Ceramic Kiln Ceramic Mugs Plates High Temperature Fire Kiln Trolley Shuttle kiln
It is one of the hot-selling products of Zhengzhou Yingfeng Machinery Co., Ltd.. We pride ourselves on our personalized and efficient service. In the process of continuous entrepreneurial innovation, Zhengzhou Yingfeng Machinery Co., Ltd. always adhere to the business philosophy of 'quality comes first'. We will grasp the opportunities of the times and always keep up with the industry trends. We believe that one day we will become one of the leading enterprises in the global market.
| Place of Origin: | Henan, China | Condition: | New |
| Type: | Converter | Usage: | Heat Treatment Furnace |
| Video outgoing-inspection: | Provided | Machinery Test Report: | Provided |
| Marketing Type: | Ordinary Product | Warranty of core components: | 1 Year |
| Core Components: | PLC, Engine, Bearing, Motor | Brand Name: | Yingfeng |
| Voltage: | 380V | Dimension(L*W*H): | Customized |
| Weight (T): | 8 T | Power (kW): | 30 |
| Warranty: | 1 Year | Key Selling Points: | Easy to Operate |
| Applicable Industries: | Machinery Repair Shops, Manufacturing Plant, ceramic tableware factory, porcelain mugs factory, pottery factory, ceramic plates factory | Showroom Location: | None |
| Product Name: | High Temperature Fire Kiln Trolley | Max Temperature:: | 1400.C |
| Useful Volume: | 3-200 | Kilncar: | 1-15set |
| Max. Setting Width: | 4200mm | Max. Setting Height: | 1800mm |
| Flue Gas Temp: | < 250c | Firing Cycle: | 16-168hr |
| Energy Consumption: | 1800+Kcal/-10%kgware | Keyword: | shuttle kiln burner |
Content | Unit | Value |
Useful Volume | m3 | 3-200 |
Max .Temperature | ℃ | 1400 |
Kiln Car | set | 1-15 |
Max. Setting Width | mm | 4200 |
Max.Setting Height | mm | 1800 |
Flue Gas Temp. | ℃ | < 250 |
Firing Cycle | hr | 16-168 |
Energy Consumption | Kcal/ kgware | 1800+/-10% |
Section width | Capacity (pcs/day) |
5.6 m | 70,000~100,000 (Standard brick ) |
6.8 m | 100,000~150,000 (Standard brick ) |
10.8 m | 200,000~250,000 (Standard brick ) |
13 m | 300,000~350,000 (Standard brick ) |
15.6 m | 500,000~600,000 (Standard brick ) |
Rotary tunnel kiln is improved and upgraded from traditional tunnel kiln.
Its biggest characteristic is the adobes stay still while the body of rotary kiln moves.
Kiln body are all steel structure,the circular orbit,once upon a time,in turn, divided into the dry period, preheating section, after roasting,cooling,heat preservation paragraphs. Machine and kiln body synthetic operation,iin order to characterize code. Rotation movement of the kiln body in orbit intermittent forward, front eat bricks, back end spit finished bricks,in turn ,drying, preheating,roasting,cooling,the whole process of bricks.
Fuel:natural gas,coal,diesel oil,etc.
